Corunclima DC electric refrigeration units is the Best Solution for Urban Deliveries. Especially applied to Full Electric Cargo van, Chiller van, food van, Engine van, Hybrid Van.
It can provide strong cooling air to the meat, ice cream, seafood, which can reach -20℃ to keep the freshness of the food.
Benefit
1.No need compressor feed by engine.
2.Easy and fast installation, fix condenser, evaporator, hose, wiring and charge gas, it's enough.
3.Still cooling when Engine-off at load&unload goods.
4.Cooling is fast and more cooling.
5.Multi-function control panel: digital, easy to operate, remain the status as which of previous shutdown, no need to set again and smart control.
Technical Data
|
Model |
V150TB |
|
|
Driven |
100% DC12V Powered by battery |
|
|
Temperature |
-20℃ |
|
|
Cooling Capacity |
760W(-20℃) |
|
|
Refrigerant |
R404A |
|
|
Compressor |
DC vortex compressor |
|
|
Condenser |
Fan Quantity |
1 |
|
Dimension |
856*743*165 |
|
|
Weight |
29Kg |
|
|
Evaporator |
Fan Quantity |
1 |
|
Dimension |
766*520*130 |
|
|
Weight |
12Kg |
|
| Electric Current | Application | |
| Application | +0°C | 7-8 m3 |
| -5°C | 6-7 m3 | |
| -10°C | 4-5 m3 | |
| -20°C | 2.5—3.5 m3 | |
Controller.
Digital, Easy operation. Put on dashboard
Plug-in: 220V, 380V, (Electric Standby) is Optional
Successful Cases:
Full Electric is Future, We are Already Here.
3000 sets are installed last two years, and still increasing fast.
Never Losing the Future Opportunity, Start Now.
