for 7.6m to 9.6m length box.
Condenser Front Mounted, Monoblock
Features
1.Oringal Yanmar Engine, model 3TNV76. same to Thermoking model.
2. More cooling air, cooling air easy come out.
3. Compressor：Original GEA Bock FKX40 470TK, 560TK
4. Electrical Standby: Optional 230V/3phase/50hz, 230V/3phase/60hz, 380V/3phase/60hz, 400V/3phase/50hz.
5. Mainstream engine and compressor brand (Original Yanmar, Bock)
6. Japanese Yanmar engine, low noise, low fuel cost;
7. Advanced gravity balance designing;
Technical Data
|
Model |
D1000 | ||
|
Temperature |
-20℃ | ||
|
Cooling Capacity (W) |
Engine
|
0oC/+30oC |
7925 |
| -20oC/+30oC | 5165 | ||
|
Standby |
0oC/+30oC |
6515 | |
| -20oC/+30oC | 4490 | ||
|
Body Application |
35-55m3 | ||
|
Alternator |
12V 90A | ||
|
Engine |
Original |
Japan | |
|
Brand |
Yanmar 3TNV76 | ||
|
No of cylinder |
3 | ||
|
Displacement |
1116cc | ||
|
Compressor |
Original |
Germany | |
|
|
Brand |
Bock FKX40/325TK | |
|
|
Displacement |
385CC | |
|
Refrigerant |
R404A | ||
|
Defrosting |
Hot gas defrost | ||
|
Evaporator Airflow (m3/hour) |
2580 | ||
|
Electric Standby |
AC220V/3phase/50HZ AC380V/3Phase/50HZ | ||
|
Size |
Overall Size (mm) |
1830*820*670 | |
|
|
Evaporator Cut-out Size (mm) |
1230*335 | |
|
Weight(Kg) |
475 | ||
