Coruncima UTE freezer is aimed at small refrigerated vehicles. Its first-class refrigeration performance will help you promote the intercity cold chain transportation business, whether you are a small company or a large company.
Benefit
1. More Cooling and cooling fast,
2. Long life of cooper tube condenser
3. Original Top Brand parts, Sanden, QP, TM compressor, Danfoss, etc
4. Separate design makes it easy to install.
5. Special design reduces environmental emissions and reduces noise.
6.Hot gas defrosting system help the transport refrigeration units work better.
7.Beautiful and fashion appearance.
Technical Data
|
Model |
V150F | |
|
Temperature |
-20℃ | |
|
Voltage |
DC12V/DC24V | |
|
Cooling Capacity |
920w(-20℃) | |
|
Refrigerant |
R404A | |
|
Compressor |
SD5S11/SD5S14 | |
|
Condenser |
Fan Quantity |
1 |
|
Dimension |
925*450*260mm | |
|
Weight |
24Kg | |
|
Evaporator |
Fan Quantity |
1 |
|
Dimension |
766*520*130mm | |
|
Weight |
14Kg | |
|
Application |
+5℃ |
8-10m3 |
|
-5℃ |
6-7m3 | |
|
-20℃ |
3m3 | |
Controller.Digital, Easy operation. Put on dashboard
Plug-in: 220V, 380V, (Electric Standby) is Optional
Successful Cases:
Corunclima truck transport refrigeration units have already been installed in South africa,Mexico, Chile, UAE, Qatar, Thailand, Australia, etc.
Corunclima freezer unit for UTE have been successfully working in Iran, Egypt, Russia, Kazakhstan, and Honduras.
For more cases, please contact us now, or visit our Facebook and Linkedin Page.
