Benefit
1.Keep you cool even when engine off. ( when Van parking or Waiting).
2. Easy Installation to Save Labor Cost
3.Save Engine Power. No power consumption for compressor.
4.Low Noise to Keep Comfortable Environment for the Passengers
5.pecial for Full Electrical bus, Van, Hybrid bus, EV bus.
6.Integrated Condenser and Evaporator
Technical Data
|
Model NO. |
AC100TB | |
|
Cooling Capacity |
9.6KW/32800BTU | |
|
Voltage |
DC12V/DC24V | |
|
Current |
120A(12V)/75A(24V) | |
|
Refrigerant |
R134A | |
|
Evaporator Air Flow Volume |
1600M3 /H | |
|
Compressor |
DC 12V/24V Electric Compressor | |
|
Condenser |
Fan Quantity |
2 |
|
Dimension |
Monoblock 1263*1040*198mm | |
|
Weight |
Monoblock 56Kg | |
|
Evaporator |
Fan Quantity |
2 |
|
Dimension |
NA | |
|
Weight |
NA | |
|
Applying |
4.5-6.0m Van | |
Controller.
Easy operation, Digital,. Put on dashboard
Plug-in: 220V, 380V, (Electric Standby) is Optional
Successful Cases :
Dealer wanted. OEM/ODM is available.
Why Choose us?
1. Reliable quality and competitive Price
2: Professional and well trained sales, and 24 Hours Technical support
3: Flexible payment terms
4: We offer one year warranty to our customers. We offer free spare parts if any part of the equipments under warranty needs to be replaced.
5.Local team can make product supply, installation,after-sale service more convenient.
6. TS 16949,ISO9001,ATP,EMC Test in German,CE Test in Romania,etc.
